3/4" Y Disc Filter – 120 Mesh, 14 GPM, 3/4" MNPT
was
$55.53
Special Price
$17.28
Compact 3/4" Y-style disc filter designed for small commercial irrigation systems. Provides reliable sediment protection for drip emitters, micro-sprinklers, and inline equipment up to 14 GPM. Disc filtration offers superior dirt-holding capacity compared to screen filters of equivalent size.
| Connection | 3/4" MNPT |
|---|---|
| Mesh | 120 Mesh |
| Max Flow Rate | 14 GPM |
| Max Pressure | 85 PSI |
| Filtration Area | 14 in² |
| Filter Style | Y-Style |
Availability:
In stock
SKU
RKD75
Ships Same Day
All orders placed by 12 PM local warehouse time will ship the same day. Some exclusions apply. Delivery time may increase if item isn't available in closest warehouse.
Delivery time: 2-4 business days
RKD75 – 3/4" Y Disc Filter for Commercial Drip and Micro-Irrigation
The RKD75 is a 3/4" Y-style disc filter built for small-scale commercial irrigation lines where protecting downstream emitters and nozzles from sand, organic matter, and sediment is critical. The 120-mesh disc cartridge captures particles down to approximately 130 microns, making it well suited for drip tape, micro-sprinklers, and inline drip systems operating at up to 14 GPM and 85 PSI.
Key Features and Benefits
- Y-Style body orientation — allows inline installation with minimal pressure loss and straightforward cartridge removal for cleaning without disconnecting the line
- 120-mesh disc cartridge — standard filtration level for most drip and micro-irrigation applications; disc construction holds more debris than equivalent screen filters before requiring service
- 3/4" MNPT connection — fits standard 3/4" female threaded fittings and valve inlets common in commercial irrigation manifolds
- 85 PSI maximum working pressure — suitable for typical field and greenhouse operating pressures
- 14 in² filtration area — generous surface area relative to body size extends cleaning intervals
Technical Specifications
Spare Parts
- Body O-Ring: RKY75-BODYORING
- Cartridge O-Ring: RKY75-CARTORING
| Discs | 120 Mesh |
|---|---|
| Inlet / Outlet | 3/4" MNPT |
| Maximum Pressure | 85 PSI |
| Maximum Flow Rate | 14 GPM |
| Filtration Surface Area | 14 in² |
