Munro LP1502B3 High-Pressure Self-Priming Pump – 2 HP, 3-Phase
was
$3,430.00
Special Price
$2,229.50
The Munro LP1502B3 is a 2 HP 3-phase self-priming centrifugal pump built for high-pressure turf and agricultural irrigation. Delivering multi-stage-like pressure output from a single brass impeller, it achieves 40–70 PSI operating pressure and 80 PSI shutoff — ideal for commercial operations requiring elevated pressure from surface water sources with the efficiency advantages of 3-phase power.
| Horsepower | 2 HP |
|---|---|
| Phase | 3-Phase |
| Discharge / Suction | 1.5" / 2" |
| Flow Range | 38–75 GPM |
| Operating Pressure | 40–70 PSI |
| Shutoff Pressure | 80 PSI |
| Max Temperature | 180°F |
| Max Suction Lift | 15 ft |
| Weight | 115 lbs |
| Impeller | Brass (single-stage) |
| Wear Ring | Stainless Steel |
| Body | Cast Iron |
Availability:
In stock
Only 2 left
SKU
LP1502B3
Munro LP1502B3 – 2 HP 3-Phase High-Pressure Self-Priming Centrifugal Pump
The Munro LP1502B3 provides the high-pressure output of the LP1502B with the energy efficiency and smooth operation of a 3-phase motor. Designed for commercial turf and agricultural irrigation systems that draw from surface water sources, it delivers up to 80 PSI shutoff pressure from a single-stage brass impeller design. Self-priming up to 15 ft from ponds, lakes, streams, cisterns, and shallow wells.
Key Features and Benefits
- 3-Phase Motor: Lower operating current, reduced energy costs, and smoother operation vs. single-phase equivalent.
- High-Pressure Output (up to 80 PSI shutoff): Supports long pipe runs, elevated zones, and high-pressure sprinkler heads.
- Multi-Stage Performance, Single-Stage Simplicity: Elevated pressure without multi-stage maintenance complexity.
- Self-Priming up to 15 ft: Draws from ponds, lakes, streams, or cisterns without submersible equipment.
- Brass Impeller: Corrosion-resistant for long service life in clean water applications.
- Cast Iron Body: Rugged construction for outdoor commercial pump installations.
Specifications
| Horsepower | 2 HP |
|---|---|
| Phase | 3-Phase |
| Discharge / Suction | 1.5" / 2" |
| Flow Range | 38–75 GPM |
| Operating Pressure | 40–70 PSI |
| Shutoff Pressure | 80 PSI |
| Max Temperature | 180°F |
| Max Suction Lift | 15 ft |
| Weight | 115 lbs |
| Impeller | Brass (single-stage) |
| Wear Ring | Stainless Steel |
| Body | Cast Iron |
