2" Y Disc Filter – 120 Mesh, 53 GPM, 2" MNPT
was
$143.27
Special Price
$91.99
2" Y-style disc filter for commercial irrigation mainlines and sub-mains requiring mid-to-high flow capacity. Handles up to 53 GPM at 130 PSI with a 51 in² disc filtration area, providing robust sediment protection for drip systems and precision emitters on larger agricultural zones.
| Connection | 2" MNPT |
|---|---|
| Mesh | 120 Mesh |
| Max Flow Rate | 53 GPM |
| Max Pressure | 130 PSI |
| Filtration Area | 51 in² |
| Filter Style | Y-Style |
Availability:
In stock
SKU
RKYD200
Ships Same Day
All orders placed by 12 PM local warehouse time will ship the same day. Some exclusions apply. Delivery time may increase if item isn't available in closest warehouse.
Delivery time: 2-4 business days
RKYD200 – 2" Y Disc Filter for Commercial Agricultural Irrigation
The RKYD200 is a 2" Y-style disc filter built for commercial agricultural mainlines and high-pressure irrigation systems. Rated to 130 PSI and capable of handling 53 GPM, it is well suited for zone inlets feeding drip tape, micro-sprinklers, or other precision emitters on medium-to-large farm irrigation systems. The 51 in² filtration area provides substantial dirt-holding capacity between service intervals.
Key Features and Benefits
- 130 PSI pressure rating — compatible with high-pressure pump systems and mainlines common in commercial agriculture
- 51 in² filtration area — large disc surface extends service life between cleanings, reducing maintenance labor on active growing systems
- Y-Style body — inline installation with side-access cartridge removal; no need to disconnect the main line for routine cleaning
- 120-mesh disc cartridge — captures sediment, sand, and organic particles at approximately 130 microns; disc construction holds more debris volume than equivalent screen filters
- 2" MNPT connection — standard thread for 2" mainline fittings, valves, and pump discharge connections used throughout commercial agricultural irrigation
Technical Specifications
| Discs | 120 Mesh |
|---|---|
| Inlet / Outlet | 2" MNPT |
| Maximum Pressure | 130 PSI |
| Maximum Flow Rate | 53 GPM |
| Filtration Surface Area | 51 in² |
