IrrigationKing 2" T Screen Filter – 120 Mesh, 130 GPM
was
$254.89
Special Price
$177.56
The RKTS230 is a 2" T-style screen filter for commercial and agricultural irrigation mainlines. The stainless steel mesh screen traps sediment and debris to protect drip emitters, sprinkler nozzles, and control valves. Rated to 110 PSI. Filtration area: 129.0 in². Compatible replacement cartridges: RKTS340-CART80, RKTS340-CART120, RKTS340-CART150.
| Connection Size | 2" MNPT |
|---|---|
| Filter Style | T-Style |
| Screen Mesh | 120 Mesh |
| Nominal Flow Rate | 130 GPM |
| Max Flow Rate | 140 GPM |
| Max Operating Pressure | 110 PSI |
| Filtration Area | 129.0 in² |
| Body Material | Polypropylene |
| Screen Material | Stainless Steel |
| Cartridge Diameter | 4.76" (122mm) |
| Cartridge Length | 15" (382mm) |
Availability:
In stock
SKU
RKTS230
Ships Same Day
All orders placed by 12 PM local warehouse time will ship the same day. Some exclusions apply. Delivery time may increase if item isn't available in closest warehouse.
Delivery time: 2-4 business days
RKTS230 – 2" T Screen Filter, 120 Mesh, 130 GPM nom / 140 GPM max
The RKTS230 is a 2" T-style inline screen filter built for commercial irrigation systems. UV-protected polypropylene body with stainless steel screen. The 120 mesh stainless steel screen intercepts particles before they reach drip emitters, micro-sprinklers, and solenoid valves. At up to 140 GPM and 110 PSI, this filter suits high-flow mainlines on farms, nurseries, and municipal irrigation networks.
Key Features and Benefits
- 120 Mesh Stainless Steel Screen – Suited for drip tape, micro-sprinkler, and emitter protection (125 micron openings), protecting emitters and nozzles from fine sediment.
- 129.0 in² Filtration Area – Large screen surface reduces cleaning frequency and maintains consistent flow under partial fouling.
- 130 GPM nom / 140 GPM max – Sized for 2" commercial mainlines operating at high agricultural flow rates.
- 110 PSI Pressure Rating – Handles high-pressure mainline supply without risk of housing failure.
- Polypropylene Body – UV-stabilized and corrosion-resistant for long outdoor service life.
- Replaceable Cartridge – Compatible with RKTS340-CART80, RKTS340-CART120, RKTS340-CART150. Swap mesh size without replacing the body.
Construction
Body: polypropylene. Screen: stainless steel mesh. Clamp: stainless steel. Seals: EPDM O-rings. Connection: 2" MNPT.
Spare Parts Available:
- O-Ring Large Filter Main Body (D230N, D350N, D490N, TS230, TS340, TS350, TS225NSA, TS340NSA, RKTS490, HC225, HC350): RKT-ORING
- Stainless Clamp Main Body (D230N, D350N, D490N, TS230, TS340, TS350, TS225NSA, TS340NSA, RKTS490, HC225, HC350) : RKSS-CLAMP
- RKTS-CARTORING (TS230, TS340, TS350, TS225NSA, TS340NSA, RKTS490): RKTSCART-ORING
- Male x Female 3/4" staight thread ball valve(TS230, D230N, TS340, TS350, TS490, D490): RK1BV34-S
- 80 Mesh - Screen Filter Cartridge (RKTS230, RKTS340, RKTS340NSA): RKTS340-CART80
- 120 mesh - Screen Filter Cartridge (RKTS230, RKTS340, RKTS340NSA): RKTS340-CART
- 150 mesh - Screen Filter Cartridge (RKTS230, RKTS340, RKTS340NSA): RKTS340-CART150
